Long Read Range ISO18000 EPC GEN2 UHF RFID Sticker
Quick facts about UHF RFID tags
1. Most do not have a battery and are powered exclusively by electromagnetic waves.
2. They do not require a line of sight, unlike barcodes.
3. The way that tags couple, or talks to, the RFID reader is called “backscatter”.
4. An algorithm on each tag called “Anti-Collision” defines the order in which to reply if multiple tags are in the reading area.
5. The read range can vary from inches to over 120 feet depending on the tag.
6. The integrated circuit (IC) has four memory banks – EPC, TID, User, Reserved.
7. Each type of tag has a uniquely shaped antenna to ensure the best reactance.
| Parameters | |
| Chip | ALIEN H3 |
| Memory | 512bit |
| Frequency | 860-960MHz |
| Protocol | ISO18000-6C / EPC GEN2 |
| Size | 97*23mm |
| Material | Coated paper / PVC / PET |
| Antenna model | 9654 |
| Read range | 6m |
| Common Chip Types | Protocol | Capacity | Anti-collision | Function |
| Available 125KHz Chip | ||||
| TK4100 | / | 64 bit | No | Read Only |
| EM4200 | / | 128 bit | No | Read Only |
| EM4305 | / | 512 bit | No | Read/Write |
| T5577 | / | 330 bits | No | Read/Write |
| Available 13.56MHz Chip | ||||
| NTAG 213 | ISO14443A | 180 byte | No | Read/Write |
| NTAG 215 | ISO14443A | 540 byte | No | Read/Write |
| NTAG 216 | ISO14443A | 924 byte | No | Read/Write |
| MIFARE Classic 1K | ISO14443A | 1 KB | No | Read/Write |
| MIFARE Classic 4K | ISO14443A | 4 KB | No | Read/Write |
| MIFARE Plus S 1K | ISO14443A | 2 KB/4 KB | No | Read/Write |
| MIFARE Ultralight EV1 | ISO14443A | 48 byte | No | Read/Write |
| MIFARE Ultralight C | ISO14443A | 144 byte | No | Read/Write |
| ICODE SLIX | ISO15693 | 896 bit | Yes | Read/Write |
| Available 860-960MHz Chip | ||||
| Alien H3 | ISO18000-6C | 512 bit | Yes | Read/Write |
| Other chips are also available. | ||||
| NTAG are registered trademarks of NXP B.V. and are used under license.ICODE are registered trademarks of NXP B.V. and are used under license.MIFARE and MIFARE Classic are trademarks of NXP B.V.MIFARE and MIFARE Ultralight are registered trademarks of NXP B.V. and are used under license.MIFARE and MIFARE Plus have registered trademarks of NXP B.V. and are used under license. | ||||
Package
Application
Goods Identification, Cargo Security, Asset Management, Access control, etc
